Do you know how to root the latest Android 4.3 XXUDMJ7 OTA Update Firmware on the Samsung Galaxy Note 3 LTE device? It’s not a rocket science which can’t be understood through a step-by-step instructional guide. Here’s the entire manual process that will help you to succeed in this exercise.
Pre-requisites:
- This step-by-step rooting tutorial is exclusively for Samsung Galaxy Note 3 LTE device model number N9005. Do not use this article and the files listed here for any other device.
- Disable all security programs from your computer. Programs such as antivirus, firewall or antimalware programs need to be removed before starting this process. This kind of software can interfere with the root process and can interrupt the same.
- Disable or uninstall the KIES program before starting the rooting process.
- Download and install the Samsung USB drivers for your Galaxy Note 3 LTE device from here.
- Ensure that the USB Debugging mode from Developer Options menu is enabled. If the Developer Options menu isn’t listed, go to About Phone menu, open this section and tap seven times on the “build number” section.
- This guide and all instructions listed here are provided only for educational and instructional purposes. Knowing that we (Android Source Team) can’t be held liable or responsible for any data loss or damage to your device.
- Ensure that the device’ battery power level is more that 60 %; otherwise the device can get a forced power off in the middle of the rooting procedure.
- Read all information listed here and do not skip any step and its correct order for installation.
- Back-up all your data stored into device’ internal memory. The rooting process is a complex operation, and you never know what can happen.
- Users who didn’t understand very clearly, what we explained here or have any other questions are invited to use the comment section.
How to root Android 4.3 XXUDMJ7 Jelly Bean for Galaxy Note 3 LTE N9005:
- First, download the CF Auto Root zip file from here and save it to the PC.
- Now, extract the downloaded contents of the zip file and save its content on your PC’s desktop folder.
- Next, download the ODIN 3 v3.07 from here, save it in your PC and extract the zip files on your computer.
- Turn off the smartphone.
- Boot the Note 3 LTE device into Download Mode, to do this press and keep holding the Volume Down, Home simultaneously and release all the buttons when a Warning! Message is displayed, then press the Volume Up button to load the Download Mode Menu.
- Now, open the folder where you extracted the ODIN zip file and launch the Odin v3.07. exe. file on your computer.
- Next, connect the Galaxy Note 3 LTE device with your PC using the USB cable.
- If the ODIN application doesn’t recognize the Note 3 device, you need to reinstall the USB drivers once again to your PC, repeat the entire step by step root procedure from beginning.
- Now, in ODIN application click the PDA button and then browse your computer contents for the CF-Auto-Root tar.md5 file.
- Load the CF-Auto-Root tar.md5 file in ODIN application.
- Make sure that the Re-Partition option is disabled and do not make any other default settings to ODIN.
- Next, click START button from ODIN to start the rooting process.
- When the root process is done, ODIN software will say ‘PASS’ message, then the Galaxy Note 3 LTE device will get an automatically reboot in normal mode.
- Now, disconnect the smartphone from computer by removing the USB cable, the device will display the Samsung boot animation logo.
- When the device will enter for the first time into normal mode you can take control over your smartphone.
Troubleshooting:
If the ODIN application doesn’t complete the root process, the Galaxy Note 3 LTE enters into a boot loop or you’ll receive any other issues, you have to:
- Close the ODIN application
- Disconnect the smartphone from PC.
- Remove the smartphone’s battery
- Reinsert the battery back into its place after five seconds.
- Repeat the entire step by step rooting guide once again from the start.
If the ODIN application root process is done, the smartphone doesn’t pass the Samsung boot animation, you need to apply a forced factory Reset. This action will wipe all content and data from the system partition, it will force the device to boot into normal mode.
How to apply the Factory Reset for Samsung Galaxy Note 3 LTE model number N9005
- First, remove the device’s battery for seven second.
- Now, insert the device’s battery into its place.
- Boot the device into stock Recovery Mode (Press and keep holding the Volume UP, Home and Power buttons simultaneously and release the buttons, when the stock Recovery screen is displayed.
- From the Recovery Mode Menu, select the “wipe data/factory reset” and confirm.
- When the wipe data and factory reset are complete, select “reboot system now” option.
Congratulation, now you successfully learnt how to root the Galaxy Note 3 LTE model number N9005 running Android 4.3 XXUDMJ7 OTA Update.
For any other questions, please use our comment section from below.
